EVOLUTION OF DURABILITY
Thanks to its resistance to elevated temperatures, alcohol and chemicals, Nylon is particularly useful for mechanical and technical applications. It is extremely durable, strong, and unbreakable. It is easily machined with tools designed for metal processing and it is also easily painted, which makes it even more versatile and functional.
It is incredibly flexible – it expands by 50% before it breaks. However, it is not resistant to concentrated alkalis and acids.
APPLICATION:
- Mechanical parts: guides, gears (cog wheels)
- Technical components: slide bearings, nuts
PROPERTIES:
- High resistance to elevated temperatures and chemical compounds
- High flexibility
- Resistant to abrasion
Diameter | Diameter Tol | Oval Tol | Printing Temp | Table Temp |
1.75mm | +/- 0.02 | +0.01 | 255-270°C | ca. 100°C |
HOW TO PRINT:
The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to choose the appropriate settings for a specific printer and printing conditions.
Nozzle Temperature | 255-270°C |
Bed Temperature | 90-110°C |
Closed Chamber | Required |
Fan | 0-10% |
Flowrate | 95-105% |
Printing Speed | 35-60 mm/s |
Surface | Glass, Kapton, PVA Glue, Hairspray, Magigoo |
Retraction (direct) | 1.5-3mm |
Retraction (bowden) | 4-6mm |
Retraction Speed | 20-45 mm/s |
Drying Conditions | 70°C / 4 hours |
