Product Description
Creatbot PEEK-300 3D Printer
The leader of ultra-high performance 3D printers
- Ultra-high temperature, nozzle / bed
- Advanced thermal system
- Direct Annealing System
- Water cooling / heat isolation system
- Medical / Industry application
Product Parameters
Printing
| Build Volume: |
Single Extrusion: 300x300x400mm Dual Extrusion: 240x300x400mm |
| Filament Diameter: | 1.75mm |
| Number of Nozzles: | Dual Extruder |
| Print Speed: | 10-120mm/s |
| Nozzle Diameter: | 0.4mm (0.3-1.0mm optional) |
Filament Compatibility
| Filament Compatibility: | Engineering Plastics: |
| PLA, ABS, ASA, PC, Nylon, PETG, PVDF, TPU, Carbon Fiber. High-temperature Material: Ultra-PA, Ultra PA-GF, UltraPA-CF, PPSU, PEI(ULTEM). Ultra-performance material: PEEK, CF-PEEK (Carbon fiber), GF-PEEK (glass fiber), PEKK, etc. |
Software
| Software: | Creatware, Simplify3D, Cura, Slic3r |
| Operating Systems: | Win7/8/10 |
| Print File Type: | STL, OBJ, AMF, G-code |
Special Function
| Outage Restored: | Saved data when the power is off |
| Filament Detection: | Pause printing when the filament runs out |
| Direct Annealing System (DAS): | The annealing process is instantly controllable during printing. It aims to provide the best quality parts, first time without warping and cracking of big sized functional prints and materials |
| Heat Insulation: | Triple heat insulation |
| Emergency Stop Switch: | Supports emergency stop |
| High Temperature Accessories: | High temperature resistance motors, linear rails, belts, and circuits to ensure extended time and high-temperature printing |
Temperature
| Nozzle Maximum Temperature: | 500°C |
| Chamber Temperature: | 120°C |
| Build Platform Maximum Temperature: | 200°C |
| Direct Annealing Temperature: | 0-400°C |
Mechanical
| Cooling: | Air Pump and Water Cooling |
| Platform: | PCB Aluminium + PEEK print board |
| Positioning Precision: | X Y axis 0.0127mm, Z axis 0.00125mm |
| Extruder: | Direct Drive |
| Machine Construction: | Fully enclosed with a heated chamber |
| Bed Levelling | Manually / Automatic |
Electrical
| Input Power: | 240V, 20A |
| Rated Power: | 4600W |
| Screen: | 4.3" full colour touch screen, multi-language |
| Print Method: | USB Connectivity / USB Drive |
Size and Weight
| Machine Size: | 650x600x750mm |
| Net Weight: | 100kg |
| Package Size: | 820x720x1080mm |
| Gross Weight: | 130kg |
